Grease for winch


AMS417

"The Ayatollah of rock and rolla"
Supporting Member
Joined
Apr 13, 2020
Messages
1,507
Location
Springfield MO
Here's the vid, cued up to the relevant spot:


He says to run the outside of the ring gear "dry", then spray a bit of WD-40 on the outside every couple of months.
My clutch lever was super hard to turn. Shot of WD-40 really helped. Need to pull mine apart and service it.


mrblaine

Crew Member
Supporting Member
Joined
Nov 20, 2015
Messages
19,287
Location
Quail Valley, CA
Here's the vid, cued up to the relevant spot:


He says to run the outside of the ring gear "dry", then spray a bit of WD-40 on the outside every couple of months.
Having seen a sliding gear fully rusted to the inside of the housing and the bottom of the shift lever sheared off from the owner trying to engage the winch out of free spool, there is no way in hell I'm running the outside of that ring gear dry. WD-40 is shit for rust prevention. It is a great solvent, pretty good cutting fluid for aluminum, it sucks at everything else.

  • Like
Reactions: srimes
OP
Claybirdd

Claybirdd

TJ Enthusiast
Joined
Oct 27, 2020
Messages
227
Location
Alabama
  • Like
Reactions: SvtLdr

Zorba

"The Veiled Male"
Supporting Member
Joined
Apr 2, 2020
Messages
5,853
Location
Merritt Island, Fl
Having seen a sliding gear fully rusted to the inside of the housing and the bottom of the shift lever sheared off from the owner trying to engage the winch out of free spool, there is no way in hell I'm running the outside of that ring gear dry. WD-40 is shit for rust prevention. It is a great solvent, pretty good cutting fluid for aluminum, it sucks at everything else.
That's why I actually used 30 wt - for better or worse.


freedom_in_4low

Sacred Order of the Coil Spring
Supporting Member
Joined
Sep 26, 2019
Messages
3,092
Location
Edmond, OK
after regreasing it with whatever AeroShell formula I found listed as the recommendation from Warn, mine free spooled so easily that I see no need whatsoever to use anything thinner like motor oil.

  • Like
Reactions: Zorba

tworley

Bent Currie Club
Supporting Member
Ride of the Month Winner
Joined
May 23, 2018
Messages
6,084
Location
Arvada, CO
Had trouble engaging/disengaging my clutch and used a moly grease I had sitting around for my motorcycle. Was much easier to engage the clutch afterwards. That was a year or so ago and it still feels great.

  • Like
Reactions: SvtLdr

Blackjack

TJ Addict
Joined
Dec 16, 2018
Messages
1,265
Location
Kenai
Here's the vid, cued up to the relevant spot:


He says to run the outside of the ring gear "dry", then spray a bit of WD-40 on the outside every couple of months.

I find it interesting that a he is just saying to run some parts store CV grease and WD40. Warn makes specific recommendations on what grease should be used in their winches. With the exception of drum seals on certain models they want an arctic weight grease with a minimum of 5% moly. This is based of years of research and testing to find what performs.

The original grease that Warn specified was Aeroshell 17, a grease that was designed for lubricating sliding metal parts on aircraft landing gear. With 5% moly and a temperature range of -100f to +300f no automotive grease came even close. When Shell discontinued the Aeroshell 17 (technically replaced with the much more expensive Aeroshell 64) Warn decided to go with Philips Moly Low Temp #1. It is a bit of a compromise as it is only rated for -30f on the low side but how many of us are actually using our winches at 30 below? Another good choice is Caterpillar Extreme Application Arctic with a low operating point of -58f.

You would never see me pulling the clutch lever and spraying a solvent down the hole. One it is just running down the groove in the gear and if you spray enough in it will just pool in the bottom of the gear box and just react with the grease. And two if you are having an issue with free spooling it might be time to take the winch down and service it.

Last edited:
  • Like
Reactions: Zorba and SvtLdr
