How can I get more performance out of my 2.5?

Discussion in 'TJ Frequently Asked Questions' started by StG58, Mar 5, 2017.

  1. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    TJ SE's and the 2.5 liter engine

    There's a lot of discussion around the Jeep 2.5 liter engine and how to increase horse power and torque.

    The short answer is, you can't. No one likes that answer, but it's the truth. The 2.5 is what it is. There are a lot of reasons to purchase an SE. Lighter weight, lower purchase price, successfully burns anything that looks and smells like regular pump gas, simpler and slightly less expensive to maintain are among of them. Oh, and they last bloody forever!

    The common modifications that are attempted to gain performance are:
    4.0 Throttle body
    Throttle body spacer
    Cold air induction
    High flow air filters
    IAC sensor relocation
    Ford yellow top, 4 hole injectors
    Headers
    Cat back exhaust system
    Power chips
    Electric fans

    Some of the less common modifications are:
    Roller rockers
    High performance cams
    Ported and polished heads
    Stroker kits
    Turbocharging
    Wet shot nitrous injection

    Let's start with the common modifications first.

    Intake modifications:
    The TJ SE intake system is designed, and comes from the factory, to flow more air than the 2.5 liter engine needs to produce maximum HP and torque at wide open throttle and maximum load. True fact. There are no meaningful restrictions to air flow. The engineers did a good job of designing the intake system from the start. The only way to get additional air and fuel into the combustion chambers is to put a cam with higher lift and / or longer duration in, bigger intake valves, some form of forced air induction or a wet shot nitrous system on the engine.

    Putting a 4.0 throttle body on will give me an extra 10 HP, right? Nope, sorry. Even with port matching the TB to the intake manifold, all you are gaining is the potential to flow more air. The 2.5 is really only an exotic air pump. The head will only flow so much air, and that amount is the air required to fill the combustion chambers at bottom dead center. That is especially true at lower RPMs, where our TJ SE's normally operate on the trail.

    Putting a throttle body spacer in has got to improve performance, right? Nope, with the port injection there are no gains to be had with increasing plenum volume with a throttle body spacer. This is especially true of the magic throttle body spacers that promise miracle gains from swirling the intake air. That trick is a left over from the days of carburetors, and even then it wasn't effective. The length of the intake runners and the plenum volume needs to be matched to the engine's displacement, HP and torque bands. The Jeep engineers did that already. No gain to be had there.

    Cold air induction has got to give me something, right? After all, cold air is denser than warm air! This is a true statement, as far as it goes. BUT, the difference in air temperature and air density going into the engine with a cold air induction system compared to the stock system is minimal at best. I have never seen or heard of a temperature difference greater than about 10 to 15 degrees F between a cold air system and the stock system. Most of the time the temperature difference is lower than that. The engine realistically doesn't see a difference and any power gains are unnoticeable.

    High flow air filters will get more air into my engine, right? Sorry, the stock paper element and air box flow as much air as the engine needs. It also does a much better job of filtering the intake air than any of the aftermarket air filters. It's cheaper as well, and readily available.

    So, how about relocating my IAC sensor to the air box? Again, this is only going to show a difference of a few degrees in temperature between the relocated position and the stock position. Once the engine reaches operating temperature and the ECM goes into closed loop mode, the O2 sensor takes over anyway as the ECM controls the air fuel mixture at 14.something to 1. No gains to be had there.

    High flow four hole fuel injectors are the clear ticket, right? More fuel = more power! Not going to happen, sorry. Once the engine warms up and the ECM goes into closed loop operation, the amount of fuel injected is based off of the signal from the O2 sensor. The ECM will maintain that roughly 14/1 ratio no matter how much the injectors will potentially flow.

    Now about the exhaust system:
    Headers will give me more power! Uh, no. The TJ SE exhaust system is not restrictive. It will easily flow all of the exhaust gasses that the 2.5 will generate. The only thing you will gain is noise. And probably exhaust leaks from gasket miss-matches and failures. Headers will also put more heat into your engine compartment. The chances of the tube diameter and tube length matching the power band are also probably lower than the stock cast header.

    Cat back exhaust systems are the cat's meow for performance gains. Not really. The Jeep engineers designed the exhaust system to flow the right amount of exhaust and generate the correct amount of back pressure for the 2.5. You can over scavenge the cylinders and kill performance and gas mileage with an ill designed exhaust system.

    What about an electric fan? Let's get rid of all that parasitic drag! All the new cars have them. There are reasons to have an electric fan, but for the most part, no. It takes X amount of energy to move Y amount of air through the radiator to keep the 2.5 engine properly cooled. The stock fan does a good job of that, and doesn't generate a ton of parasitic loss at normal speeds. That's what the fan viscous coupling does. There's just not enough gain there to make it worthwhile.

    A power chip will rock my 2.5! Nope, not really. You're already getting optimal air flow and the correct fuel mixture. Any gains from additional spark advance are minimal at best and will restrict the octane requirements for the 2.5.

    Now we're getting into the more old school hot rodding tricks for generating more power out of the 2.5. Forced air induction, displacement changes, compression ratio increases, that sort of things. These will increase power, but the cost goes through the roof quickly.

    Let's step back a moment and talk about what generates power. Power comes from burning a specific amount of gasoline and air at a specific ratio. We are starting out with 2.5 liters of displacement. That's not a lot of air / fuel being burned in the grand scheme of things, and it will only generate so much power. Let me repeat that. You can only burn a certain amount of the proper air / fuel mixture in the 2.5. That's all the power available out of the engine.

    We can increase the amount of power generated by increasing the compression ratio and by extension the efficiency of the engine. Doing so increases the octane rating required to prevent detonation and the destruction of the engine. One of the bonuses of the 2.5 is that it will happily burn anything that looks and smells like gasoline. So we may not want to go there.

    Another way to increase efficiency is to eliminate as much parasitic drag in the engine as we can. We can try to make as much power go to the transmission as possible. One of the ways to do that is with roller cams and roller rockers. With a four banger, that is a loosing proposition because there really isn't enough parasitic loss there to justify the expense. A full roller valve train would be expensive and result in an almost unnoticeable gain.

    We can balance and blueprint the engine, so that it operates closer to it's theoretical efficiency. Again, that's a lot of expense for not a lot of gain. I estimate that you are only going to gain 15 - 20 HP at the top end with both a roller valve train and a balanced and blueprinted engine. And you'll only see that gain in the higher RPM ranges.

    What about camming the engine? There's the possibility of gaining a little here, but we want a nice, flat HP and torque curve for the way we end up using the 2.5. Going with a lot of duration and overlap on the cam generates HP, but the power curve move up in the RPM range. Not what we are looking for. What about higher lift on the cam? We can get some gains there, and it can be done with rocker arms of a higher ratio. The longest rocker arms that will fit under the valve cover are approximately 1.6 to 1. We also have to be careful to not drive a valve into a piston doing this. Especially if you rev it and float a valve.

    How about a stroker engine? That increases the amount of fuel / air mixture being burned and generates more power! Yup, it sure does. I've seen 2.5 stoker engines go for $3000 and up. That puts you in the same HP and torque range as a stock 4.0.!That's a lot of money to turn an SE into a stock Sport or X. If you can pick up an SE for $7000 and add in $3000 for a stroker, you're not far off from a decent Sport or X. Plus you still have the AX5 to deal with in the SE. It does solve the riddle of how to burn more fuel / air.

    There's always head modifications as well. These work best in conjunction with a high lift and long duration cam. It will get more fuel / air mixture into the combustion chamber, but you'll only see the increase at higher RPM's. You can do things like bigger valves, CC'ing the heads so that all four combustion chambers are as close to the same size as possible, polishing the combustion chambers, raising the intake ports and port matching, contouring the intake valve bowl, lots of tricks to tried there. My take is that there just isn't enough displacement in the 2.5 to really make any of this worthwhile at the lower RPM ranges.

    Forced air induction. Now this works. More fuel / air into the engine = more power. My preference would be something like a roots type positive displacement blower. It would generate power from idle to wherever you lifted the throttle. With supercharging and turbocharging the 2.5, you are faced with replacing the ECM with something that would control spark and fuel management. It's out there and available, but man is it expensive and hard to find. Plus you need to program these controllers from scratch to match your engine parameters. It's a good way to end up buying another 2.5. Good thing 2.5's are cheap!

    Wet shot nitrous injection. This technology has been around since WWII, but it has nothing to recommend it to an SE owner. Just don't.

    Repeat this as many times as it takes to sink in. You CAN NOT get more power out of these 2.5 liter 4 bangers unless you want to spend some serious coin.

    All of the bolt on mods are a complete waste of money, most of them offering no performance gain at all, only an empty wallet (i.e. intakes, headers, etc.).

    The ONLY real way to improve these 4 bangers in terms of power output would be to dump $3000 plus into a stroker engine, or dump $5000 plus into a supercharger system and custom standalone engine management system.

    When you start putting that in perspective, you're better off selling your SE and getting a clean 4.0 model Wrangler. Either that, or if you really don't want to sell it, invest in a V8 swap and call it a day.

    I see it asked all the time, "How do I get more power out of my 4 cylinder?", and the way to answer that is with this simple question: "Are you prepared to spend $3000 or more?"

    And we know the answer to that question, so it's almost senseless to even ask.

    OK, now let's talk about what you can do to increase the performance of your 2.5 powered TJ SE...

    Keep the weight down. The 2.5 is perfectly happy pushing a 3,300 – 3,500 pound TJ around, especially on 31” tires. Around town, off road, on the Highway. Keep it Light for true Jeeping bliss!

    Tires, Tires, Tires. Keep your tires to 31”, 32” or 33” tires. This effects the lift you require, the weight of the rotating mass involved and keeps you in the range of available gearing for the Dana 35 / 30 that comes with your 2.5.

    Gears. You will end up changing gears out for one of two ratios. 4.88 or 5.13. That may sound pretty extreme, but those are the gear ratios that normally work the best with the 2.5 SE. Remember that the 2.5 is happy at 3,000 RPM.

    The 2.5 SE is a good little Jeep that can be purchased economically in good condition. Use it within it's performance parameters and you'll be very happy with it!

    #1 StG58, Mar 5, 2017
    Last edited: Mar 5, 2017
    Jack72, fuse, ALAN TUCKER and 10 others like this.
  2. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    Chris likes this.
  3. Chris

    Chris Administrator
    Staff Member

    Joined:
    Sep 28, 2015
    Messages:
    28,596
    Likes Received:
    17,098
    Location:
    Salem, Oregon
    I changed the title to be more descriptive, since this is indeed the commonly asked question. I also moved it to the FAQ section, in hopes that people will see this. In the very worst case, we can always just copy and paste the link.

    StG58 likes this.
  4. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    Good show @Chris, maybe we can head some folks off at the pass with this.

  5. Chris

    Chris Administrator
    Staff Member

    Joined:
    Sep 28, 2015
    Messages:
    28,596
    Likes Received:
    17,098
    Location:
    Salem, Oregon
    That's the plan. Finally put an end to the "Will a CAI and throttle body spacer give my 2.5 more power?" questions... Ha, yeah right... Those will never end. But at least now there's a thread that people can read if they feel so inclined.

    StG58 likes this.
  6. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    I really like your answer to the "How can I get more Power out of the 2.5?" question with the "Got $3,000 or more?" question. That's about the cheapest entry fee you can pony up to play in that game.

  7. Chris

    Chris Administrator
    Staff Member

    Joined:
    Sep 28, 2015
    Messages:
    28,596
    Likes Received:
    17,098
    Location:
    Salem, Oregon
    Yep, I agree.

    But there's people out there who honestly believe that CAIs, throttle body spacers, Chinese headers (if you can even call them that) and full exhausts will make a difference.

    It's all a scam, with the exception of the exhaust, which may give you a little more oomph, but not enough to be noticeable (other than sound).

    StG58 likes this.
  8. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    I've read literally multiple hundreds of threads on various forums where a 2.5 owner claims miraculous power increases from one modification or another. They have one thing in common. There is no empirical evidence to back up the claim. None. It's always "It sure feels like my SE has more performance!". Another thing you never hear is the person coming back in a week or two and saying that the performance increase is still there after the ECM gets done relearning and compensating. I have run across a half a dozen or so threads where someone has at least attempted to quantify the performance increase with with numbers generated one way or another. One fairly long term thread with multiple modifications and combinations of modifications used a long freeway on ramp and a stop watch to try and quantify the performance gains. He did see some very minor gains until the ECM remapped, but the cost of the mods were vastly outweighed by very minor performance gains, and any small gains disappeared within a week to ten days. There were a couple of other folks who used accelerometers to try and quantify their performance gains, and it was the same story. 0 to extremely minor performance gains quickly canceled out by the ECM remapping.

    I guess that if you mod your 2.5, and it makes you feel better, there isn't much to say. It falls into the same category as angry eyes, halo's and Hi-lift Jacks on the hood. Whatever floats your boat.

    The things that do work are weight control, reasonable tire sizes and GEARS.

    ALAN TUCKER likes this.
  9. Chris

    Chris Administrator
    Staff Member

    Joined:
    Sep 28, 2015
    Messages:
    28,596
    Likes Received:
    17,098
    Location:
    Salem, Oregon
    One thing that most people don't seem to compensate for, is the placebo effect.

    The mind is a powerful tool, and most don't understand that. If you hype yourself up to think that this new part coming in the mail is going to boost your engines performance, there's a very good chance that once you install it, you will indeed feel a "performance gain", that in reality doesn't even exist.

    It's your mind playing tricks on you, and the only way to disprove that would either be a dyno, or to get someone else (who had no interest) and ask them if they felt a performance gain from their butt dyno.

    It's hard to convince people about this placebo effect though, because most people either aren't smart enough to understand that, or they're simply so caught up in their "mod", that they don't want to listen to reason.

    CBRacerX and StG58 like this.
  10. JWjeepSask

    JWjeepSask TJ Enthusiast

    Joined:
    Dec 14, 2016
    Messages:
    170
    Likes Received:
    97
    Location:
    Canada
    Are they really happy at 3000rpm? I always feel like something is gonna come flying out of my hood when I take it on the highway lol


    Sent from my iPhone using Tapatalk

    Chris and StG58 like this.
  11. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    Yes. I've run the 2.5 for awhile now, like @Chis starting with an XJ, and usually keep the RPM's between 2,600 and 3,300. Torque peak is about 3,200 RPM. Running FS roads in good condition and that I know, I'll leave it in third and buzz around all day.

    PhantomX and Rob5589 like this.
  12. PhantomX

    PhantomX Member
    Supporting Member

    Joined:
    Mar 27, 2017
    Messages:
    73
    Likes Received:
    36
    Location:
    Raleigh, NC, United States
    Good read

    StG58 and Chris like this.
  13. Jake kozlowski

    Jake kozlowski New Member

    Joined:
    Feb 17, 2018
    Messages:
    10
    Likes Received:
    4
    Location:
    Elmendorf Air Force Base, Anchorage, AK, USA
    Good read. I've done some of the "mods" and it's made certain things "easier".

    The electric fan. This was a lot if fun to do and have noticed my temp gauge doesn't seem to bouce around as much. Off roading my rpms don't dip as much while it's running compared to the clutch fan. Biggest gain is all the room you gain!!!!

    The 4.0 throttle body. I notice I can set cruise control at 60mph. Feels like more pep, but also my original throttle body was a mess!!! Probably just a good cleaning was all it needed.

    Currently, 2000tj, 2.5L, 5 speed, stock 4.10 with 32s (jk Rubicon wheels and tires)

  14. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    If you do a lot of water crossings, an electric fan can be a reasonable mod in my opinion, when you couple it with other "deep water" mods. I'm not convinced you're gaining much, but every little bit helps.

    If you get the chance and the money go to 5.13 gears. The combination of 32's, 5.13s, and the AX5 is about ideal off road with the 2.5, and it still cooks right down the freeway. I bet you even see slightly better gas milage. SE's have their own quirks and rules. Give them what they want and they are totally viable Jeeps.

    Enjoy yours! To misquote another member here "We're two cans shy of a six pack" but that doesn't mean SE drivers need to be handicapped.

  15. Jake kozlowski

    Jake kozlowski New Member

    Joined:
    Feb 17, 2018
    Messages:
    10
    Likes Received:
    4
    Location:
    Elmendorf Air Force Base, Anchorage, AK, USA
    2 cans short of a 6 pack! That's awesome!!!

    Speaking of water crossings, I just ordered a new controller. I was using I believe it's the Hayden 3561 controller. Not positive. But this is the upgrade
    https://nickintimedesign.com/product/trinity-fan-controller-v2-prototype/

    Well for gearing, I have a Ford 9inch waiting for me to build in my garage .got it for a steal, so I opted for that over the 8.8. People are charging a ridiculous amount for the 8.8 up here in Alaska. 5.13 is the ratio I'm shooting for just trying to figure out a good replacement for the Dana 30.

    I've read 4.88 is a good ratio for 33s, and might save me some $$

  16. StG58

    StG58 Backwoods Amateur
    Supporting Member
    Thread Starter

    Joined:
    Oct 29, 2015
    Messages:
    5,598
    Likes Received:
    5,618
    Location:
    Orygun, the wet side...
    That was a @Jerry Bransford ism. I loved it as well. AND, he's not wrong.

    Revolution makes a nice 5.13 gear set for the Dana 30, I hear. No clue on the Ford 9". 4.88's do work fine. I prefer the 5.13's only because of my local situation. @Rob5589 has 4.88's in his SE and loves'm.

    You have to post up pictures of your Jeep travels in Alaska.

  17. Jerry Bransford

    Jerry Bransford TJ Guru
    Supporting Member

    Joined:
    Nov 9, 2015
    Messages:
    7,583
    Likes Received:
    8,475
    Location:
    Escondido California
    Speaking of Revolution Gear's gears, they just announced their new REM series of gears. They are highly polished and require NO breakin now. How about that!!?? They have a video on the process on their webpage.

    StG58 likes this.
  18. Jake kozlowski

    Jake kozlowski New Member

    Joined:
    Feb 17, 2018
    Messages:
    10
    Likes Received:
    4
    Location:
    Elmendorf Air Force Base, Anchorage, AK, USA
    I can't find a 5.13 for a Dana 30. If you have a link or reference it would be greatly appreciated! I would prefer 5.13, just because I live to go slow on the trail! No need for speed.


    Attached Files:

    StG58 likes this.
  19. Jake kozlowski

    Jake kozlowski New Member

    Joined:
    Feb 17, 2018
    Messages:
    10
    Likes Received:
    4
    Location:
    Elmendorf Air Force Base, Anchorage, AK, USA
    I have tons!!!! I might just start a thread


    Attached Files:

    StG58 likes this.
  20. Jake kozlowski

    Jake kozlowski New Member

    Joined:
    Feb 17, 2018
    Messages:
    10
    Likes Received:
    4
    Location:
    Elmendorf Air Force Base, Anchorage, AK, USA

    I will need to research this! Do you think they will be as strong or even stronger than normal gear sets?
