Steering wheel center and toe adjustment

Status
Not open for further replies.
OP
OldGuyOldJeep

OldGuyOldJeep

New Member
Joined
Nov 8, 2021
Messages
14
Location
GA
to whom ever I gave two reasons why pitman wouldn’t be strait back when gear box is centered, I totally for the 3rd reason. Pitman arm mismatched. The key the stock 5203887 pitman are something like 12.5 off center which lines up wi the stock 6530? I think I am remembering that right but if the part store gave you the “alternative” box 8413, 8412, 6532 etc.. there are a ton. The pitman arm will fit them, but the center offset is different on each part number so it throws the arm off by the difference in offset. I actually have the 108 one from the Durango in mine, and had to change pitman arms to the 8347 to match offset. 108 is great btw if you do a lot of deep mud, only 3 turns stop to stop. My make wheel shifting easy.


hosejockey61

Jeepless No More
Supporting Member
Ride of the Month Winner
Joined
Apr 9, 2020
Messages
1,869
Location
Parker, CO
It’s the middle of the day, is there day drankin’ goin on?

That would be a yes.... Water of course😂
