What did you do to your TJ today?


psrivats

TJ Addict
Supporting Member
Joined
Jun 4, 2018
Messages
1,712
Location
OR, USA
I rebuilt the np231 transfer case today, and it went pretty well.

Here it is as removed:
View attachment 97717

First thing I did was pressure wash it. And then I used a slightly-too-small hex head socket in the drain plug and stripped it out. It's the same exact thing I did to the fill plug a few months ago, so I took the same tact and ground the threads off of a big-ass bolt so that it fit into the stripped out hole and welded it in. Now I have a matching 19mm headed fill and drain plugs, and I'll never need to buy the right sized hex head.

I popped off the yoke. I don't remember using this much silicone when I installed the slip yoke eliminator. I tried using a little less during this rebuild.
View attachment 97718

I pulled off the tail housing after fighting against the silicone for a long time. I just wasn't hitting it hard enough with the rubber hammer to separate the tail from the main housing. Once it broke loose I popped out the seal and bearing and was happy to feel a little bit of grindy-ness when spinning it in my hand. Hopefully replacing this bearing gets rid of the squealing that I've been hearing. I ordered it directly from Teraflex because I assumed it would be a different bearing than the original tail housing. It's a #6207 bearing. I bought two from Teraflex, along with two seals, just in case it's a special kind of bearing and I can't source it down in Baja. Well now I know that you get a 6207 bearing in the standard np231 rebuild kit, so I have two spares.
View attachment 97719

Again it looks like I used too much silicone when sealing the case and it clogged up the filter quite a bit.
View attachment 97720

Here's my weird looking finger showing you where the oil passage needs to line up. The mounting stud with the nut on it came out when I was separating the transfer case from the transmission. I put some red locktite on it and tightened it back into the transfer case with some vise grips.
View attachment 97721

The chain and everything looked in pretty good shape. It didn't seem like it was stretched out but I replaced it all anyway.
View attachment 97722

I replaced the plastic pads on the top shift fork. The lower fork doesn't seem to have pads that are replaceable.
View attachment 97723

I've got a nice pile of parts going. I kind of like knowing that I get to do all of that degreasing, just slowly and methodically. But I also get weird stress when my only vehicle is in pieces so I kind of have a love-hate relationship with all of those little tasks that just eat up time but need to be done to feel like you did the job right.
View attachment 97724

This job was the first time I've seen this kind of snap ring - it just has a little groove for a screwdriver to pop it out of it's nook, and then you get to try to grab it with some other little implement to pry it the whole way out.
View attachment 97725

I pulled out the planetary gear to get to the final bearings. The snap ring that keeps in the planetaries is comically large and I wish I'd taken a photo of it.
View attachment 97726

This bearing was the hardest part - I don't have any bearing pullers and I'm not sure what kind you'd need, so I just went about chiseling it down and out. It wasn't pretty and I scored the bearing surface a little bit, but not enough to hurt it I pray.
View attachment 97727

Old and slightly busted, new and complete:
View attachment 97728

Here it is all rebuilt with the new "extended" drain/fill plugs. I debated painting the whole thing but I think I'd rather be able to drive somewhere tomorrow. I put a coat of paint on the cross-member, taking it from orange back to satin black, and I also painted the transmission mount because it was pretty crusty.
View attachment 97729

The rebuild kit came with a bunch of spare parts - or at least I hope so :D
View attachment 97730
Great writeup and great photos.

@Chris you should add this to the how-to section!

  • Like
Reactions: Chris

xxdabroxx

TJ Enthusiast
Joined
Mar 31, 2017
Messages
873
Location
Central California, CA, United States
Ordered it a spiderwebshade and rear bumper braces. My old mesh shade was pretty rotten at the end of last summer so I tossed it. Looking forward to the spider shade.

Bumper also needs the braces as the last time I tried moving my dads dump trailer in my driveway it looks like it sagged it pretty bad. Hopefully the poison spider braces help shore it up quite a bit. Should also help if I get/ make a rack to go in the hitch for extra camping gear storage.


Willys LJ

TJ Enthusiast
Joined
Oct 26, 2018
Messages
317
Location
Dyer TN
Finally got those pesky transfer case fill and drain plugs to budge after spraying them last week with some Kroil and letting them set. I didn't even have to go to the big breaker bar I use to wreck stuff or heat anything up. I might need to go get a lottery ticket.

Oh, and the ATF in the transfer case looks almost new and it's full. One less worry. Now to get back to some serious stuff like getting those fool doors off.


mikespine

Member
Joined
Nov 4, 2018
Messages
77
Location
Holly Springs, NC
Wired my 3rd brake light to a swing-away tire carrier.. Tapped into the original wire coming right out of the swing away tailgate. (black is hot +12V, white is ground). Stripped wire, crimped with heat shrink butt connectors, added heat, wire loomed with black electrical tape. The wire loom falls nicely. I mignt zip tie...we'll see.

Not my idea: thanks to www.stu-offroad.com









Bababooey

TJ Enthusiast
Joined
Oct 4, 2016
Messages
226
Wired my 3rd brake light to a swing-away tire carrier.. Tapped into the original wire coming right out of the swing away tailgate. (black is hot +12V, white is ground). Stripped wire, crimped with heat shrink butt connectors, added heat, wire loomed with black electrical tape. The wire loom falls nicely. I mignt zip tie...we'll see.

Not my idea: thanks to www.stu-offroad.com



View attachment 98939
Nice. I always cut the wires at different spots (stagger the cuts) so that the butt connectors are spaced apart, and not on top of each other. Makes the harness less bulky and easier to fit inside a loom. Looks like you had lots of room in the loom so it didn’t really matter here, but just thought I’d throw it out there as it’s a useful thing to remember when wiring.


Leinhit

TJ Enthusiast
Joined
Sep 26, 2017
Messages
296
Location
US
Removed the seats and nasty carpet, then used Eastwood rust converter rubberized spray to treat it.

Should got a close up of the nasty front passenger door pan...

Looks great now, the spray stays somewhat soft so I need to cover it. Maybe the bedrug since I have not found just a simple think rubber mat like a work truck to replace the carpet.

I expect a quiet ride too.



Sent from my XT1575 using Tapatalk


Kiwi TJ

I don't suffer from insanity I enjoy every minute
Supporting Member
Ride of the Month Winner
Joined
May 3, 2016
Messages
4,499
Location
Auckland New Zealand
Removed the seats and nasty carpet, then used Eastwood rust converter rubberized spray to treat it.

Should got a close up of the nasty front passenger door pan...

Looks great now, the spray stays somewhat soft so I need to cover it. Maybe the bedrug since I have not found just a simple think rubber mat like a work truck to replace the carpet.

I expect a quiet ride too.

View attachment 99060View attachment 99061View attachment 99062

Sent from my XT1575 using Tapatalk
Did you paint not under the center console ?


Leinhit

TJ Enthusiast
Joined
Sep 26, 2017
Messages
296
Location
US
Did you paint not under the center console ?
No I didn't, I had it out not to long ago to move it back so not to interfere with shifting after the lift kit.

It was in good shape under and I didn't feel like taking it out again, etc. But I certainly can if I get the ambition later.

I have also been doing the same under the tub and on the frame to get it from both sides

Sent from my XT1575 using Tapatalk

  • Like
Reactions: Kiwi TJ

mikespine

Member
Joined
Nov 4, 2018
Messages
77
Location
Holly Springs, NC
Nice. I always cut the wires at different spots (stagger the cuts) so that the butt connectors are spaced apart, and not on top of each other. Makes the harness less bulky and easier to fit inside a loom. Looks like you had lots of room in the loom so it didn’t really matter here, but just thought I’d throw it out there as it’s a useful thing to remember when wiring.
That's a great idea. You are correct, the loom from Rugged Ridge was a little bigger so I did have some room. Thanks for the input...next time I'll stagger cuts.
