Hey guys quick question...

Ive got an 02 jeep tj that doesn't have Factory cruise control however im hoping to use the parts off a 2000 or 2001 xj to change that!
If so, would I be able to use the parts on my tj? are they all compatible, maybe just some? or non at all?
if so can I mix and match?

to my understanding even though I don't have factory CC if I get the:
- servo assembly
- wiring assembly to connect servo to tj wiring loom
- speed control switches and clock spring
I should be able to plug into into my existing tj loom and all will be well?

hope you guys can help!

Last edited:
thebarrabuggy said:
Hey guys quick question...

Ive got an 02 jeep tj that doesn't have Factory cruise control however im hoping to use the parts off a 2000 or 2001 xj to change that!
If so, would I be able to use the parts on my tj? are they all compatible, maybe just some? or non at all?
if so can I mix and match?

to my understanding even though I don't have factory CC if I get the:
- servo assembly
- wiring assembly to connect servo to tj wiring loom
- speed control switches and clock spring
I should be able to plug into into my existing tj loom and all will be well?

hope you guys can help!
Click to expand...

I have done it on my 02,you can use the switches,the clock spring works(just have to open the center up a little with a dremel .and have to get a schematic an run like four new wires to the ecm and two to the brake switch.
