Ideal All-Purpose RPM for Re-Gearing

Yoda

TJ Enthusiast
Joined
May 5, 2021
Messages
171
Location
MA
I'm putting 33x10.5's on my 98 TJ with an AX-15 and 4.0L. The motor is going to be stroked and should have peak torque somewhere around 3000RPM hopefully. It will be an all purpose rig, 85% highway cruising during the week, probably 80 miles per day commuting almost all highway. Will play in the woods on the weekends. Mostly rough fire roads, logs, random rocks. Not a dedicated rock crawler or mud bogger.

What do you think the ideal RPM's would be for best MPG on the highway but also good for off-roading when needed? I tend to drive the speed limit or so, about 65-70MPH on the highway.

I was thinking 2500RPM is a good middle ground to shoot for. The .79 5th OD gear, with 33's and 4.56's gives me 2400RPM at 65mph . With 4.88's I'm at 2550RPM at 65mph.

Would 4.56's or 4.88's be better for fuel economy?

Yes I know it's a Jeep not a Honda, so please don't tell me I should have bought a Honda Civic. I somewhat care about the environment and if I can burn less gas while having fun, I'll do it. And if I'm going through everything and re-gearing I might as well try and get the best gas mileage I can while still having fun in the woods.

Thoughts?

  • Like
Reactions: Kon and TJim

JMT

The Jeep Guy
Supporting Member
Ride of the Month Winner
Joined
Feb 27, 2017
Messages
17,356
Location
🌎
488’s will be better for fuel economy.


machoheadgames

LED turn signal club
Supporting Member
Joined
Jan 21, 2021
Messages
935
Location
Dallas, TX
For those two rpm numbers I would expect mpg to be around the same. 150 rpm isn't going to make or break mpg in either direction. If you will never go past 65 I'd probably just do 4.88. If you will want to drive faster, I'd probably go 4.56 since it's a stroker with more power. On the plain 4.0, I'd definitely do 4.88/33 (and I did).

OP
Yoda

Yoda

TJ Enthusiast
Joined
May 5, 2021
Messages
171
Location
MA
If you will never go past 65 I'd probably just do 4.88. If you will want to drive faster, I'd probably go 4.56
65-70mph is a typical cruise speed. If traffic is moving at 75-80mph I'll jump in but not as common. With 4.88's if I wanted to go 75mph I'm at 2950rpm. 80mph is 3150rpm.

4.56's is 2750rpm @75mph and 2950rpm @80mph.

But....like I said in the first post, most of it's life will be at 70ish.

Which RPM will give me the best fuel economy at 65-70mph?


Woodrow

TJ Enthusiast
Supporting Member
Joined
May 25, 2021
Messages
331
Location
Oregon
I have a '97 w/ a Golen stroker, AX-15 and 4.11 gears on 33s. I daily drive it w/ a country road commute. RPM is about 2000 at 60mph in 5th. It will accel up a hill from 60 in top gear but I usually shift to 4th. At 75 on the highway, it feels strong. I think 4.56 would be fine also, but 4.88 might be too much for me. I get about 13 mpg which is down from 15 w/ the 4.0, 31s and 3.07 gears.


freedom_in_4low

Sacred Order of the Coil Spring
Supporting Member
Joined
Sep 26, 2019
Messages
4,588
Location
Edmond, OK
as others have said...the difference isn't going to show up in fuel economy.

It might show up in how pleasant it is to drive.

I was happy with 4.56/AX15/33s, but I had a lot of 75mph speed limits where traffic goes 80+. If 65-70 was really top end, I'd probably go 4.88. The reason being is that (IMO) the 4.0's happiness changes a fair amount between 2400 and 2550. I like to target closer to 2700-2800 for cruise speed. I'm ~2675 at 65mph (with 35/4.88/NSG370) and would probably downshift to climb a hill at that speed.

  • Like
Reactions: SvtLdr
OP
Yoda

Yoda

TJ Enthusiast
Joined
May 5, 2021
Messages
171
Location
MA
Not that it is a deal breaker, but how buzzy/loud/annoying is the engine cruising in the 2750ish RPM range if at all? Does the 4.0l care?

FYI...the stroker is going to be a DIY combo of the "modified poor man's stroker" and either a gasket-matched head done by myself or if I want to cough up some coin get the ported TUPY head from Newcomer. Probably a Comp Cam's 231 or 232 cam. Shooting for 9.5:1 compression or so and 87-89 octane. Prioritizing low and mid range torque.


machoheadgames

LED turn signal club
Supporting Member
Joined
Jan 21, 2021
Messages
935
Location
Dallas, TX
I've never found it to be annoying at all cruising in the 27-2800 range or even at 3000. I found 2400-2500 to be a bit anemic feeling myself, but that may change with a stroker. I know a big aspect of the stroker is having the torque come alive quicker than the 4.0 which you get with the 4.2 crank. I'd personally do the engine first, then figure out where you want to be from what you have now.

Or like myself and many others did, regear the 4.0, and determine that it's good enough to not want to mess with an engine build anymore. But you sound serious on the stroker so I'd probably do that first and evaluate the ratio to pick after, if you can sequence things that way.

But, if you still want to make a decision now, I don't think you'd hate 4.88 based on how you say you'll drive it. If you wanted to fly down the road at 80 mph all the time, then you maybe would want 4.56 instead.

  • Like
Reactions: L J

TheBoogieman

MoreBS
Supporting Member
Joined
Jan 1, 2019
Messages
5,731
Location
C-Ville VA
Not that it is a deal breaker, but how buzzy/loud/annoying is the engine cruising in the 2750ish RPM range if at all? Does the 4.0l care?

FYI...the stroker is going to be a DIY combo of the "modified poor man's stroker" and either a gasket-matched head done by myself or if I want to cough up some coin get the ported TUPY head from Newcomer. Probably a Comp Cam's 231 or 232 cam. Shooting for 9.5:1 compression or so and 87-89 octane. Prioritizing low and mid range torque.
The 4.0 prefers higher rpms and mine isn't loud at all. I did have a 32rh auto with 4.56 gears and 32s. It got the worst highway MPGs of any Jeep I've ever owned.

Last edited:
  • Like
Reactions: SvtLdr

Slicknick630

Member
Joined
Apr 4, 2021
Messages
41
Location
New port Richey, Florida
In my 01 TJ 4.0 4spd trans with 35s and 4.88 gears I run about 3100-3200 rpm at 65 mph if I could do it different I would have done more research to get those rpm’s down on the highway for when I drive out to do some off-roading. I just went with what my local off-road shop told me before I knew what type of wheeling I was going to be doing. I just said I have 35s and want to regear. You give and take with gears that’s for sure. I am definitely interested in what other think and how their setups compare.

  • Like
Reactions: Woodrow

freedom_in_4low

Sacred Order of the Coil Spring
Supporting Member
Joined
Sep 26, 2019
Messages
4,588
Location
Edmond, OK
Not that it is a deal breaker, but how buzzy/loud/annoying is the engine cruising in the 2750ish RPM range if at all? Does the 4.0l care?

FYI...the stroker is going to be a DIY combo of the "modified poor man's stroker" and either a gasket-matched head done by myself or if I want to cough up some coin get the ported TUPY head from Newcomer. Probably a Comp Cam's 231 or 232 cam. Shooting for 9.5:1 compression or so and 87-89 octane. Prioritizing low and mid range torque.

I don't notice it, but mine isn't a stroker. You'll have more piston velocity, and being an inline 6 theoretically cancels out the primary and secondary imbalances but I don't have experience there.

  • Like
Reactions: SvtLdr

machoheadgames

LED turn signal club
Supporting Member
Joined
Jan 21, 2021
Messages
935
Location
Dallas, TX
In my 01 TJ 4.0 4spd trans with 35s and 4.88 gears I run about 3100-3200 rpm at 65 mph if I could do it different I would have done more research to get those rpm’s down on the highway for when I drive out to do some off-roading. I just went with what my local off-road shop told me before I knew what type of wheeling I was going to be doing. I just said I have 35s and want to regear. You give and take with gears that’s for sure. I am definitely interested in what other think and how their setups compare.
From the factory, an 01 auto is 3 speed and the manual is 5 speed. Guessing you have the 3 speed. Most people going with 35's on the 3 speed choose 4.56. There is always some give and take on the gearing vs rpm with the 3 speed auto because you don't have overdrive.

  • Like
Reactions: L J

Jerry Bransford

TJ Guru Moderator
Staff Member
Supporting Member
Joined
Nov 9, 2015
Messages
23,738
Location
Fleming Island Florida
Not that it is a deal breaker, but how buzzy/loud/annoying is the engine cruising in the 2750ish RPM range if at all? Does the 4.0l care?
The 4.0 doesn't care at all, I loved my 2750 70 mph cruising rpms with my previous TJ with 4.88 and 35's with the 5-speed. My current TJ has 5.38 gears with 35's but with the 4-speed automatic. Its 70 mph rpms are more like 2550 which is not quite enough.

  • Like
Reactions: SvtLdr

machoheadgames

LED turn signal club
Supporting Member
Joined
Jan 21, 2021
Messages
935
Location
Dallas, TX
The 4.0 doesn't care at all, I loved my 2750 70 mph cruising rpms with my previous TJ with 4.88 and 35's with the 5-speed. My current TJ has 5.38 gears with 35's but with the 4-speed automatic. Its 70 mph rpms are more like 2550 which is not quite enough.
When you move to FL and won't be doing any more heavy wheeling, you could downsize to 33's and enjoy getting some of the rpm back :)

Although I suppose you're set up for 35's in many other ways.

  • Like
Reactions: Jerry Bransford

SvtLdr

Search Engine Certified Mechanic
Supporting Member
Ride of the Month Winner
Joined
Nov 26, 2019
Messages
1,762
Location
NE Indiana
Not that it is a deal breaker, but how buzzy/loud/annoying is the engine cruising in the 2750ish RPM range if at all? Does the 4.0l care?
As mentioned above, the 4.0 performs very well at that RPM. By the time you're moving that fast, there are a number of other things that make a lot more noise than the engine.


SvtLdr

Search Engine Certified Mechanic
Supporting Member
Ride of the Month Winner
Joined
Nov 26, 2019
Messages
1,762
Location
NE Indiana
When you move to FL and won't be doing any more heavy wheeling, you could downsize to 33's and enjoy getting some of the rpm back :)

Although I suppose you're set up for 35's in many other ways.
Jerry's plans for Florida retirement...


...oh yeah, that's an ANGRY GRILL!
