Going from 4" lift to 3" lift?

J

Je.m8792

New Member
Joined
Jan 21, 2024
Messages
7
Location
Sevierville, TN
Hi all, first time poster long time reader. As the title states I'm playing with the thought of going from a 4" lift to 3" suspension lift.
Picked up a 2000 wrangler sport that has a bare bones 4" RC lift with a 1" t-case drop. Currently running 285/75 16s with 1.5" spacers and stock steering with fox damper.
The jeep is my dd and will mostly be road driven besides the weekend mountain driving and some gravel/dirt roads.
Wondering what all is involved and if I can tackle the majority of the work myself? I want to do it right if I do this.

Welcome to the forum! I grew up not all that far from Sevierville (near Kingsport, but on the VA side).

While I don't blame you for working to get rid of the RC lift, what are you trying to to accomplish by going to a 3"? Are you just going to a better brand lift and don't need 4" for your needs or is there something else?

Je.m8792 said:
Hi all, first time poster long time reader. As the title states I'm playing with the thought of going from a 4" lift to 3" suspension lift.
Picked up a 2000 wrangler sport that has a bare bones 4" RC lift with a 1" t-case drop. Currently running 285/75 16s with 1.5" spacers and stock steering with fox damper.
The jeep is my dd and will mostly be road driven besides the weekend mountain driving and some gravel/dirt roads.
Wondering what all is involved and if I can tackle the majority of the work myself? I want to do it right if I do this.
Click to expand...

It’s just like adding a 3” lift. You remove the springs, put the shorter springs in, change the shocks, adjust the trackbars and control arms, get smaller tires, et al. Hard to say exactly without seeing exactly how it is built now.

  • Like
Reactions: TJTom and D M
Rut Row said:
Maybe he's height challenged and tired of bringing a stool to get into his Jeep. I find that a TJ lifted to suit us average guys is far to tall for a lot of people. (Work with me here, I'm trying to be PC).
Click to expand...

Are you saying @Kiwi TJ is a hobbit? ;) I'm only 5' 9" and have zero problems getting into my lifted Jeep on 35s. I don't need to hold on to grab handles or steering wheel either. Put leg in, push off with other leg. Done.
p.s. That doesn't work for my 5' 3" "round" wife. She uses the grab handles to pull herself in.

Last edited:
  • Haha
Reactions: Rut Row
Rut Row said:
Maybe he's height challenged and tired of bringing a stool to get into his Jeep. I find that a TJ lifted to suit us average guys is far to tall for a lot of people. (Work with me here, I'm trying to be PC).
Click to expand...

I'm a short fuck & that was a huge factor in lowering my TJ, and I ain't done lowering it yet!

  • Like
Reactions: Rut Row
Westtown Willy said:
I'm a short fuck & that was a huge factor in lowering my TJ, and I ain't done lowering it yet!
Click to expand...

Tom Cruise or Peter Dinklage short?



Last edited:
  • Haha
Reactions: GPK03X
bbaldwin237 said:
Welcome to the forum! I grew up not all that far from Sevierville (near Kingsport, but on the VA side).

While I don't blame you for working to get rid of the RC lift, what are you trying to to accomplish by going to a 3"? Are you just going to a better brand lift and don't need 4" for your needs or is there something else?
Click to expand...
Thanks for the response, have family in Penington Gap area and Bristol VA.

I have no need for the 4" lift and want to make it better getting in and out for the family and still want a beefy look to it. 3" lift will be plenty for what I'll be doing. Of course I want a better ride quality, but hoping with a 3" lift I can achieve that without a sye and aca's. I want to ditch the wheel spacers and go to 15" wheels. I wouldnt want anything bigger than 33x10.5 tires either. Would like to avoid a body lift also. Looking at replacing/refreshing any bushings, linkages, ujoints, bearings, etc while doing this. Would like the lift to be under $2k if possible. Not sure what shocks/springs to go with. I want somthing that will handle the bumpy pot hole roads of East TN. And not sure about the bump stops.
Am I delusional with my expectations? Lol.

  • Like
Reactions: bbaldwin237
JMT said:
It’s just like adding a 3” lift. You remove the springs, put the shorter springs in, change the shocks, adjust the trackbars and control arms, get smaller tires, et al. Hard to say exactly without seeing exactly how it is built now.
Click to expand...

I'll post some pics later, thanks

JMT said:
It’s just like adding a 3” lift. You remove the springs, put the shorter springs in, change the shocks, adjust the trackbars and control arms, get smaller tires, et al. Hard to say exactly without seeing exactly how it is built now.
Click to expand...

I'll post some pics later
Westtown Willy said:
I'm a short fuck & that was a huge factor in lowering my TJ, and I ain't done lowering it yet!
Click to expand...

This here is my main factor, having a back surgery a little over a year ago makes this more practical in my mind.

TheBoogieman said:
Tom Cruise or Peter Dinklage short?
View attachment 494526

View attachment 494527
Click to expand...

I share height parity with Maverick at 5'7" and shrinking, perhaps if I'm still around in 30 years I'll be closer to Dinklage, I already share his other muppetesque qualities

Je.m8792 said:
Of course I want a better ride quality, but hoping with a 3" lift I can achieve that without a sye and aca's.
Click to expand...

you're in the zone there where an SYE may be necessary. You may be able to avoid it with a TC skid drop & some other tweaks. Keep in mind you wouldn't need the adjustable arms all the way around, in a pinch you can get away with rear uppers, I've been running that scam successfully for years

  • Haha
Reactions: TheBoogieman
Westtown Willy said:
I share height parity with Maverick at 5'7" and shrinking, perhaps if I'm still around in 30 years I'll be closer to Dinklage, I already share his other muppetesque qualities



you're in the zone there where an SYE may be necessary. You may be able to avoid it with a TC skid drop & some other tweaks. Keep in mind you wouldn't need the adjustable arms all the way around, in a pinch you can get away with rear uppers, I've been running that scam successfully for years
Click to expand...

TheBoogieman said:
Are you saying @Kiwi TJ is a hobbit? ;) I'm only 5' 9" and have zero problems getting into my lifted Jeep on 35s. I don't need to hold on to grab handles or steering wheel either. Put leg in, push off with other leg. Done.
p.s. That doesn't work for my 5' 3" "round" wife. She uses the grab handles to pull herself in.
Click to expand...

I'm same height but after having my l4-l5 bolted together and a prosthetic disc in there it makes it a little challenging. I can do it tho.

Je.m8792 said:
I'll post some pics later


This here is my main factor, having a back surgery a little over a year ago makes this more practical in my mind.
Click to expand...

I don’t think you’ll meet your family friendly goal just dropping from 4” to 3” lift, even if you drop tire size from 33 to 32. A 1” lift and 31’s would be more appropriate.

Je.m8792 said:
Thanks for the response, have family in Penington Gap area and Bristol VA.

I have no need for the 4" lift and want to make it better getting in and out for the family and still want a beefy look to it. 3" lift will be plenty for what I'll be doing. Of course I want a better ride quality, but hoping with a 3" lift I can achieve that without a sye and aca's. I want to ditch the wheel spacers and go to 15" wheels. I wouldnt want anything bigger than 33x10.5 tires either. Would like to avoid a body lift also. Looking at replacing/refreshing any bushings, linkages, ujoints, bearings, etc while doing this. Would like the lift to be under $2k if possible. Not sure what shocks/springs to go with. I want somthing that will handle the bumpy pot hole roads of East TN. And not sure about the bump stops.
Am I delusional with my expectations? Lol.
Click to expand...

As @Westtown Willy mentioned, you'll probably still need a TC drop or SYE at 3". I currently have a 3" lift with a 1" TC drop and 33x10.5s. the drop is necessary on mine, though some have slightly different results. 3" is typically where the vibes will start to come along.

You could probably stick with your 4" springs, upgrade bushings and shocks, and maybe do an SYE and stay under/around your $2k? If you are sticking with 33's, I don't know that dropping an inch will make that much visible difference, and you're only gaining 1/2" of drop for entry. You may not even gain anything since some springs measure over or under their advertised lift. So if your RC springs have sagged or measure short and your new 3" springs measured tall, you might not gain anything??

  • Like
Reactions: Paparock1
bbaldwin237 said:
As @Westtown Willy mentioned, you'll probably still need a TC drop or SYE at 3". I currently have a 3" lift with a 1" TC drop and 33x10.5s. the drop is necessary on mine, though some have slightly different results. 3" is typically where the vibes will start to come along.

You could probably stick with your 4" springs, upgrade bushings and shocks, and maybe do an SYE and stay under/around your $2k? If you are sticking with 33's, I don't know that dropping an inch will make that much visible difference, and you're only gaining 1/2" of drop for entry. You may not even gain anything since some springs measure over or under their advertised lift. So if your RC springs have sagged or measure short and your new 3" springs measured tall, you might not gain anything??
Click to expand...
Thanks, this is the kind of info I'm looking for.

  • Like
Reactions: bbaldwin237
Just reading through the thread.

You understand the Cost and Labor involved isn't really worth anything going from a 4" lift to a 3" lift, correct?
I say this NOT in a demeaning way.

The requirements of the Jeep to operate/drive well are pretty much the same between 3" and 4".
(SYE, Adjustable arms, etc)

To add onto that, you'd be spending X amount of money and labor, for a literal inch. Probably the thickness of the sole of your shoe.
Which will make no discernable difference to ride quality, nor do I think you'd ever notice it in terms of comfort or getting in-out.

I just see it as a waste of money and effort to drop from a 4" down to a 3", given the common ground of both options.

I think what suits you AND your wallet better is dropping down to a 1"-2" lift height, and a more aggressive 31" wheel/tire combo.
